MODEL |
|
LRS-35-5 |
LRS-35-12 |
LRS-35-15 |
LRS-35-24 |
LRS-35-36 |
LRS-35-48 |
|
OUTPUT |
DC Voltage |
5V |
12V |
15V |
24V |
36V |
48V |
|
Rated Current |
7.0A |
3.0A |
2.4A |
1.5A |
1.0A |
0.8A |
|
|
Current range |
0~7.0A |
0~3.0A |
0~2.4A |
0~1.5A |
0~1A |
0~0.8A |
|
|
Rated power |
35W |
36W |
36W |
36W |
36W |
38.4W |
|
|
Ripple&noise |
80mVp-P |
120mVp-p |
120mVp-p |
150mVp-p |
200mVp-p |
200mVp-p |
|
|
Voltage ADJ. |
4.5~5.5V |
10.2~13.8V |
13.5~18V |
24~28V |
32.4~39.6V |
43.2~52.8V |
|
|
Voltage tolerance |
±2.0% |
±1.0% |
±1.0% |
±1.0% |
±1.0% |
±1.0% |
|
|
Line regulation |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
|
|
Load regulation |
±1.0% |
±1.0% |
±0.5% |
±1.0% |
±0.5% |
±0.5% |
|
|
Setup,Rise,Time |
1000ms, 30ms/230VAC 2000ms, 30ms/115VAC at full load |
||||||
|
Hold up time |
30ms/230VAC 12ms/115VAC at full load |
||||||
|
INPUT |
Voltage range |
100～264VAC 140～373VDC |
|||||
|
Frequency range |
50~60Hz |
||||||
|
Efficiency |
80% |
85% |
85% |
87% |
87% |
88% |
|
|
AC current |
0.7A/115VAC 0.42A/230VAC |
||||||
|
Inrush current |
Cold start: 45A/230VAC |
||||||
|
Leakage current |
<0.75mA/240VAC |
||||||
|
PROTECTION |
Over load |
115%~150% in rated output power |
|||||
|
Protection type: Hiccup mode, recovers automatically after fault condition is removed |
|||||||
|
Over voltage |
5.75~6.9V |
13.8~16.2V |
18.75~21.75V |
28.8~33.6V |
41.4~48.6V |
55.2~64.8V |
|
|
Protection mode, tum off output voltage, restart to recover |
|||||||
|
Environment |
Working TEMP |
-10℃~+60℃. |
|||||
|
Working humidity |
20~65% RH non-condensing |
||||||
|
Storage TEMP humidity |
-10℃~+60℃，10-95% RH |
||||||
|
TEMP.coefficient |
±0.03%℃ (0~50℃) |
||||||
|
Vibration |
10~500Hz，5G 10min./1cycle . 60min Each along X,Y,Z axes. |
||||||
|
SAFETY |
Safety regulations |
UL60950-1,TUV EN60750-1 In line with the certification |
|||||
|
Withstand voltage |
I/P-O/P:1.5KVAC I/P-FG:1.5KVA O/P-FG:0.5KVAC |
||||||
|
Insolation resistance |
I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC |
||||||
|
Electromagnetic compatible emission |
Compliance to EN55032(CISPR32 )Class B, EN61000-3-2,-3, EAC TP TC 020 |
||||||
|
EMC immunity requirements |
Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024,EN1000-6-2(EN50082-2), Class A heavy Industry standard, |
||||||
|
OTHERS |
MTBF |
≥760K hrs.MIL-HDBK-217F(25℃) |
|||||
|
Dimension |
99*82*30mm(L*W*H) |
||||||
|
Packing |
0.2Kg:60PCS/13Kg/0.85CUFT |
||||||
